specifications for the dbx DriveRack VENU360:

Audio Specifications - *Inputs:*    - 3 analog line inputs/2 AES digital inputs (shared connectors)

   - 1 RTA mic input    - Input Connectors: 3 female XLRs (2 selectable between analog/AES digital audio formats), 1 female XLR RTA mic input - *Input Type:* Electronically balanced/RF filtered

- *Input Impedance:* > 30 kΩ, balanced line to line - *Max Input Level (line inputs):* > +28 dBu, balanced, ≤1% THD - *CMRR:* > 50 dB @ 1 kHz Output

 Specifications - *Outputs:* 6 line outputs - *Output Connectors:* Male XLR - *Output Type:* Electronically balanced, RF filtered - *Output Impedance:* 120 Ω, balanced line to line - *Max Output Level:* +22 dBu, balanced, ≤1% THD Processing Specifications - *A/D Converter:* 24-bit with dbx Type IV Conversion System - *D/A Converter:* 24-bit - *Internal Processing Wordlength:* 32-bit floating point - *Supported Sample Rates:* 48/96 kHz (32-192 kHz using sample rate conversion) Performance Specifications - *Dynamic Range:* 114 dB A-weighted; 110 dB unweighted - *THD+Noise:* 0.0025% typical at +4 dBu, 1 kHz, 0 dB input gain - *Frequency Response:* 20 Hz – 20 kHz, +0 /- 0.5 dB - *Latency:*    - Analog input to output: 2.57 ms (48 kHz), 2.28 ms (96 kHz)    - Digital AES input to output: 2.31 ms (48 kHz), 2.15 ms (96 kHz) Physical Specifications - *Dimensions:* 1.75” (H) x 8.0” (D) x 19” (W) (4.4cm x 20.32cm x 48.26cm) - *Unit Weight:* 5.48 lbs. (2.49 kg) - *Shipping Weight:* 7.10 lbs. (3.22 kg) - *Operating Voltage:* 100-240 VAC 50/60 Hz - *Power Consumption:* 18 W ¹
